HMUSA 2022 Conference: VFD Cables – Essential or Overkill

About the presentation
This presentation answers the questions:

• What is a variable frequency drive (VFD) cable and why do VFD cable constructions differ so much?
• Why do high-frequency pulse width modulation (PWM) waveforms create problems that don’t exist with 60Hz?
• What is radiated electromagnetic interference (EMI) and how can VFD cable reduce it?
• What is electromagnetic coupling and how can VFD cable reduce it?
• Why is common mode current a problem?
• How can VFD cables reduce undesirable effects of common mode current?

It also addresses:

• The importance of proper shield termination
• The dangers of using THHN cables between an inverter and motor
• Reflected Waves and Corona Inception Voltage
• The NFPA 79 and what it says about drive cable
• 600V, 1000V, and 2000V rated cable, what you need
• Cost differences between VFD cable and standard cable
• Various VFD cable constructions on the market
